M5A1 Stuart
The first tanks of the M5 series were produced in April 1942, and a new modification, the M5A1, was preferred over other variants. After the M24 Chaffee was developed, the M5A1 tanks were deemed obsolete and were exported to other countries, including China. A total of 100 tanks of this type were supplied to the Kuomintang. During the Civil War (1946–1949), many of these vehicles were captured by the PLA.
M3A3
SCR 508
SCR 506
Twin Cadillac, Series 42
Continental R-975-C1
VVSS T36E6
VVSS T55E1
Shell Types:
AP
APCR
HE
AP
APCR
HE
Equipment:
Consumables:
Firepower: | |||||||||
Ammunition | 185 (rounds) | ||||||||
Caliber | 37 (mm) | ||||||||
Damage | 40 / 40 / 50 (HP) | ||||||||
Penetration | 56 / 78 / 19 (mm) | ||||||||
Rate of Fire | 26.09 (rounds/min) | ||||||||
Average Damage per Minute | 1043 (HP) | ||||||||
Shells in the Magazine | |||||||||
Time for Loading Between Shots | (s) | ||||||||
Time for Complete Loading | (s) | ||||||||
Gun Loading | 2.30 (s) | ||||||||
Aiming Time | 1.70 (s) | ||||||||
Dispersion at 100 m | 0.42 (m) | ||||||||
Mobility: | |||||||||
Weight/Load Limit | 15.56 / 15.75 (t) | ||||||||
Engine Power | 296 (h.p.) | ||||||||
Specific Power | 19.02 (h.p./t) | ||||||||
Top Speed | 64.4 (km/h) | ||||||||
Reverse Speed | 20 (km/h) | ||||||||
Traverse Speed | 36 (deg/s) | ||||||||
Turret Traverse Speed | 48 (deg/s) | ||||||||
Survivability: | |||||||||
Hit Points | 495 (HP) | ||||||||
Hull Armor | 28 / 28 / 25 (mm) | ||||||||
Turret Armor | 38 / 31 / 31 (mm) | ||||||||
Spotting: | |||||||||
View Range | 330 (m) | ||||||||
Signal Range | 395 (m) | ||||||||
Crew: | |||||||||
|
